Zooming range of   objectives

0.7x-4.5x, ratio   1:6.5

Eyepieces

SWF10x/22mm

Working distance

95mm

Interpupillary   distance

adjustment

55-75mm

Viewing head

inclination of 45°,   360°rotatable, binocular or trinocular

Diopter   adjustment

±5 diopter

Power supply

AC110-240V   50/60Hz

Illumination

DC 12V 10W   halogen projection (top) and transmitted (inside base) lamp,

both adjustable brightness, optional LED illumination

Optional   eyepieces

WF5x, WF15x,   WF20x, WF25x

Optional barlow   lens

0.3x, 0.5x,   0.75x, 1x, 1.5x, 2x

Optional   accessories

XY moving   working stage, rotatable working stage, tilting working stage,

darkfield stage,   CCD or CMOS camera, specimen holder, aluminium

carrying case
